FA-015
folansi
FA-015
| Name:Air source heat pump/Air to water heat pump(60degree)heating+hot water | |||||
| Model | unit | FA-015 | FA-02 | ||
| Rated heating capacity | KW | 4.83 | 7.1 | ||
| BTU | 16485 | 24232 | |||
| Hot water supply | T/h | 0.1 | 0.15 | ||
| Average heating input power | KW | 1.15 | 1.7 | ||
| Rated heating input current | A | 4.71 | 7.11 | ||
| Max outlet water temp | ℃ | 60℃ | |||
| COP | 4.2 | 4.18 | |||
| Power | V/Hz | 220-240V/50HZ | |||
| Nosie | dB(A) | 45 | 47 | ||
| Dimension | Width | mm | 930 | 1000 | |
| Deepth | mm | 280 | 300 | ||
| Height | mm | 550 | 620 | ||
| Unit weight | KG | 75 | 85 | ||
| Throttling type | Electronic expansion valves/thermal expansion valves | ||||
| Refrigerant | R410A;R32 | ||||
| Working air temp range | – 20℃～45℃ | ||||
| Compressor | Type | Panasonic,hitachi | |||
| Security functions | Built-in protection device overheating protection, sequence protection, undervoltage protection, delay protect | ||||
| Air source heat exchanger | Type | Finned heat exchange | |||
| Qty | piece | 1 | |||
| Fan type | Axial big twist Angle fan | ||||
| Motor power | KW | 0.04 | 0.05 | ||
| Hot water side heat exchange | Type | Efficient tube to tube heat exchanger/tube in shell heat exchanger | |||
| Water flow | m3/H | 0.84 | 1.22 | ||
| Water pressure down | kPa | 20 | 20 | ||
| Pipe size | Inch | 3∕4 | |||
| Water side max working pressure | kPa | 1000 | |||
| Remarks:the test conditions of above parameter:dry bulb temp is 20℃.wet buld temp is 17℃.inlet water temp is 15℃.outlet water temp is 60℃ | |||||
