FA-08
folansi
FA-08
| Model | unit | FA-08 | ||
| Rated heating capacity | KW | 27 | ||
| BTU | 92150 | |||
| Hot water supply | T/h | 0.58 | ||
| Average heating input power | KW | 5.9 | ||
| Rated heating input current | A | 28(220V) | ||
| 11(380V) | ||||
| Max outlet water temp | ℃ | 60℃ | ||
| COP | 4.6 | |||
| Power | V/Hz | 220-240V/380-415V/50HZ | ||
| Nosie | dB(A) | 55 | ||
| Dimension | Width | mm | 1450 | |
| Deepth | mm | 780 | ||
| Height | mm | 1050 | ||
| Unit weight | KG | 225 | ||
| Throttling type | Electronic expansion valves | |||
| Refrigerant | R410A/R32 | |||
| Working air temp range | – 20℃～45℃ | |||
| Compressor | Type | Scroll Copeland,.hitachi,panasonic | ||
| Security functions | Built-in protection device overheating protection, sequence protection, undervoltage protection, delay protect | |||
| Air source heat exchanger | Type | Finned heat exchange | ||
| Qty | piece | 1 or 2 | ||
| Fan type | Axial big twist Angle fan | |||
| Motor power | W | 50*2 | ||
| Hot water side heat exchange | Type | tube in shell heat exchanger/plate heat exchanger | ||
| Water flow | m3/H | 4.66 | ||
| Water pressure down | kPa | 34 | ||
| Pipe size | Inch | 1 | ||
| Water side max working pressure | kPa | 1000 | ||
| Model | unit | FA-08 | ||
| Rated heating capacity | KW | 27 | ||
| BTU | 92150 | |||
| Hot water supply | T/h | 0.58 | ||
| Average heating input power | KW | 5.9 | ||
| Rated heating input current | A | 28(220V) | ||
| 11(380V) | ||||
| Max outlet water temp | ℃ | 60℃ | ||
| COP | 4.6 | |||
| Power | V/Hz | 220-240V/380-415V/50HZ | ||
| Nosie | dB(A) | 55 | ||
| Dimension | Width | mm | 1450 | |
| Deepth | mm | 780 | ||
| Height | mm | 1050 | ||
| Unit weight | KG | 225 | ||
| Throttling type | Electronic expansion valves | |||
| Refrigerant | R410A/R32 | |||
| Working air temp range | – 20℃～45℃ | |||
| Compressor | Type | Scroll Copeland,.hitachi,panasonic | ||
| Security functions | Built-in protection device overheating protection, sequence protection, undervoltage protection, delay protect | |||
| Air source heat exchanger | Type | Finned heat exchange | ||
| Qty | piece | 1 or 2 | ||
| Fan type | Axial big twist Angle fan | |||
| Motor power | W | 50*2 | ||
| Hot water side heat exchange | Type | tube in shell heat exchanger/plate heat exchanger | ||
| Water flow | m3/H | 4.66 | ||
| Water pressure down | kPa | 34 | ||
| Pipe size | Inch | 1 | ||
| Water side max working pressure | kPa | 1000 | ||
