FA-25
folansi
FA-25
| Air source heat pump/Air to water heat pump(60degree)heating+hot water（ WIFI controller) | |||||||
| Model | unit | FA-15 | FA-20 | FA-25 | FA-30 | ||
| Rated heating capacity | KW | 57.1 | 76 | 95 | 110 | ||
| BTU | 194881 | 259386 | 324232 | 395665 | |||
| Hot water supply | T/h | 1.53 | 1.93 | 2.34 | 2.96 | ||
| Average heating input power | KW | 12.2 | 16.2 | 20.5 | 24.6 | ||
| Rated heating input current | A | 19.99 | 26.51 | 33.1 | 38 | ||
| Max outlet water temp | ℃ | 60℃ | |||||
| COP | 4.67 | 4.69 | 4.63 | 4.7 | |||
| Power | V/Hz | 380-415V/50HZ | |||||
| Nosie | dB(A) | 63 | 65 | 65 | 70 | ||
| Dimension | Width | mm | 1900 | 1700 | 1800 | 2305 | |
| Deepth | mm | 1010 | 900 | 1010 | 1100 | ||
| Height | mm | 1050 | 1215 | 1215 | 1860 | ||
| Unit weight | KG | 440 | 520 | 600 | 720 | ||
| Throttling type | Electronic expansion valves | ||||||
| Refrigerant | R410A， R32 | ||||||
| Working air temp range | – 20℃～45℃ | ||||||
| Compressor | Type | Scroll Copeland,.hitachi,panasonic | |||||
| Security functions | Built-in protection device overheating protection, sequence protection, undervoltage protection, delay protect | ||||||
| Air source heat exchanger | Type | Finned heat exchange | |||||
| Qty | piece | 2 | |||||
| Fan type | Axial big twist Angle fan | ||||||
| Motor power | W | 550*2 | 550*2 | 550*2 | 550*3 | ||
| Hot water side heat exchange | Type | tube in shell heat exchanger OR Shell tube heat exchanger | |||||
| Water flow | m3/H | 9.81 | 13.07 | 16.3 | 18 | ||
| Water pressure down | kPa | 40 | 41 | 43 | 45 | ||
| Pipe size | Inch | 1-1∕2 | 2 | 3 | |||
| Water side max working pressure | kPa | 1000 | |||||
| Circulate water pump | No | ||||||
| water flow switch | Yes | ||||||
