| Quantity: | |
|---|---|
300L
folansi
300L
| Heat pump Water tank | |||||||
| Specification | Inner Specification | tank body foaming | inner material | outer casing material | body dimensions | packing size | powder coating (white,Silver.Red,Blue,Gold,SUS201 8k surface,SUS304 8k surface) |
| (M M) | thickness(MM) | (M M) | (M M) | (M M) | |||
| 80L | φ370*1.0 | 50 | SUS304 | powder coating/430 stainless steel/304 stainless steel | φ470*900 | 550*530*930 | |
| 100L | φ370*1.0 | φ470*1070 | 545*545*1115 | ||||
| 150L | φ370*1.0 | φ470*1528 | 545*545*1590 | ||||
| 200L | φ470*1.0 | φ560*1211 | 640*640*1290 | ||||
| 250L | φ470*1.2 | φ560*1598 | 640*640*1630 | ||||
| 300L | φ470*1.2 | φ560*1850 | 640*640*1885 | ||||
| 400L | φ600*1.5 | φ700*1574 | 780*780*1650 | ||||
| 500L | φ600*1.5 | φ700*1928 | 780*780*2015 | ||||
| 600L | φ600*1.5 | φ700*2198 | 780*780*2300 | ||||
| 800L | φ800*2.0 | φ800*2300 | 900*900*2450 | ||||
| Heat pump Water tank | |||||||
| Specification | Inner Specification | tank body foaming | inner material | outer casing material | body dimensions | packing size | powder coating (white,Silver.Red,Blue,Gold,SUS201 8k surface,SUS304 8k surface) |
| (M M) | thickness(MM) | (M M) | (M M) | (M M) | |||
| 80L | φ370*1.0 | 50 | SUS304 | powder coating/430 stainless steel/304 stainless steel | φ470*900 | 550*530*930 | |
| 100L | φ370*1.0 | φ470*1070 | 545*545*1115 | ||||
| 150L | φ370*1.0 | φ470*1528 | 545*545*1590 | ||||
| 200L | φ470*1.0 | φ560*1211 | 640*640*1290 | ||||
| 250L | φ470*1.2 | φ560*1598 | 640*640*1630 | ||||
| 300L | φ470*1.2 | φ560*1850 | 640*640*1885 | ||||
| 400L | φ600*1.5 | φ700*1574 | 780*780*1650 | ||||
| 500L | φ600*1.5 | φ700*1928 | 780*780*2015 | ||||
| 600L | φ600*1.5 | φ700*2198 | 780*780*2300 | ||||
| 800L | φ800*2.0 | φ800*2300 | 900*900*2450 | ||||
